Thermal Grease ,Heat Sink Compound

Description

Fasto TG100 is one part high performance siliconebased non curing thermally conductive paste. FastoTG100 is specially formulated for various applicationswhere heat transfer is very imported. Fasto TG100 isthick paste and can be easily applied with the helpspatula. Fasto TG100 has very good thermalconductivity with better electrical insulation andweatherability. Its performance at high temperature isalso excellent.TYPICAL APPLICATIONSFasto TG100 , thermally conductive paste, is very usefulwhere continuous heat transfer at elevated temperatureis required. It fills the air gap between contact surfaceand ensures quick heat dissipation. Fasto TG100 isgenerally used during assembly of LED lights and otherelectronic & electrical devices.PROPERTIES OF UNCURED MATERIALValueChemical type ProprietaryColour WhiteSpecific Gravity (g/ml) 1.93Thermal conductivity (W/m-k) 1.1Operating TemperatureContinuous (°C) -50 to 200Intermittent (°C) ~250Breakdown Voltage (kV/mm) > 5.1Shelf life (months) 12DIRECTIONS FOR USERemove all the rust, scale, dirt, dust, grease, oil, releaseagents, or other contaminants from the contact surfaces.Surfaces can also be cleaned using suitable Fastocleaner. Apply Fasto TG100 evenly with spatula suchthat no air remains between heat emitting surface andheat radiating contact surfaces. Apply Fasto TG100 in sufficient quantity and wipe out the excessive quantity.Excess quantity application is avoidable.Application temperature should be between 5°C and40°C and optimum temperature range is 15°C to 25°C.GENERAL INFORMATIONSAFETY PRECAUTIONSAvoid breathing of vapors. Forced local exhaust isrecommended to effectively minimize exposure. NIOSHapproved, organic vapor respirators and forced exhaustare recommended in confined areas, or when conditions(such as sanding, etc) may cause high vaporconcentrations.For safe handling of this product consult the MaterialSafety Data Sheet.StorageOptimal storage conditions are between 15°C and 25°C.Storage outside this temperature range can adverselyaffect product properties and may affect the stated shelflife.Packaging500 g, 1 kgLIMITATIONSThis product is not recommended for use in pure oxygenand/or oxygen rich systems and should not be selectedas a sealant against chlorine or other strong oxidizingmaterialsDATA RANGESThe data contained in this data sheet may be reportedas typical value and/or range. Values are based onactual test data and are verified on a regular basis.NOTESThe information contained herein is produced in goodfaith and is believed to be reliable but is for guidance only. Fasto India and its agents cannot assume liabilityor responsibility for results obtained in the use of itsproduct by persons whose methods are outside orbeyond our control. It is the user's responsibility todetermine the suitability of any of the products andmethods of use or preparation prior to use mentioned inour literature and furthermore the user's responsibility toobserve and adapt such precautions as may beadvisable for the protection of personnel and property inthe handling and use of any of our products.
